Stax SRM-400S
Driver unit for electrostatic earspeakers
Semiconductor driver unit is redesigned. New DC amplifier which FET are installed in all stages.
Driver unit for electrostatic earspeakers
Semiconductor driver unit is redesigned. New DC amplifier which FET are installed in all stages.
Driver unit for electrostatic earspeakers
Semiconductor driver unit is redesigned. New DC amplifier which FET are installed in all stages.
PRODUCT DETAILS
Type- All-stage FET configuration DC amplification driver unit
Frequency response- DC - 90kHz (with one SR-L500 MK2)
Gain- 60dB
Harmonic distortion- 0.01% or less (1kHz/100Vrms output)
Input impedance- 50k Ω (RCA), 50k Ω x 2 (XLR)
Maximum output voltage- 400Vrms (1kHz)
Bias voltage- DC 580V
Operating temperature / humidity- 0 to 35 degrees C / less than 90% (non condensing)
Input terminal- RCA x 1, XLR x 1(mutual exclusion input)
Output- RCA parallel output terminal
Power consumption- 30W
Dimension- 195 (W) x 102 (H) x 376 (D) mm (maximum protruding portion included)
Weight- 3.4kg
