PRODUCT DETAILS
Power Amplifier Output (at rated 230/120V supply voltage) @ 1kHz 0.1% THD-
168W RMS per channel into 8Ω
305W RMS per channel into 4Ω
THD+Noise at 100W into 8Ω measurement bandwidth 22Hz to 22.4 kHz- Typically 0.015% at 1kHz
Unbalanced Input Sensitivity- 820mV at 35kΩ
Balanced Input Sensitivity- 1.64V at 26kΩ
Power Amplifier Gain- 33.3dB
Frequency Response at 100W into 8Ω (Unbalanced input)- 15Hz (-0.5dB point) to 30kHz (-0.5dB point)
Power Supply (as marked)- AC supply 230V / 220V / 120V / 100V nominal ±10%
Power Consumption- Power Consumption 500W at 1/8 rated power (42.5 W into 4Ω)
Power Consumption in Standby- 0.4W (activated automatically if no signal present after 1 hour)
Unbalanced Input Sensitivity / Impedance- 820 mV at 35kΩ
Balanced Input Sensitivity / Impedance- 1.64V at 26kΩ
Dimensions (WxHxD)- 435 x 140 x 385mm (17 x 5.5 x 15in)
Weight- 24.8 kg (54.7lbs)
