PRODUCT DETAILS
General Description- Integrated Amplifier
Design Philosophy and Core Technology-
2 x 200W (8 ohm) / 2x300W (4 ohm)
Class AB Dual Mono Design
ES9038Pro 32-bit DAC
Roon Tested
Highly linear Analogue Volume Control
4.3" 800 x 480 Full View IPS LCD
Dedicated High-performance Low Noise MM/
MC Phono stage with selectable gain (46/52/60dB)
Dedicated Current-Feedback Headphone Amp
Support USB Upgrade
Inputs-
2 x Analogue (RCA), 1 x XLR, 1 x Phono (MM / MC)
2 x SPDIF (Coaxial), 2 x SPDIF (Optical)
1 x PC USB(TYPE C) 1 x HDMI ARC
1 x 12V Trigger
Outputs-
1 x RCA (pair), 1 x XLR (pair) , 1 x Stereo Speaker binding post (pair),
1 x Optical, 1 x Coaxial, 1 x 12V Trigger
Sampling Frequency-
Optical / Coaxial: 44.1kHz - 192kHz
PC USB: 44.1kHz - 768kHz (PCM) / DSD64, DSD128, DSD256, DSD512)
Preamplifier Section
Gain- 0dB (Line) +46 / +52 / +60dB Adjustable (Phono)
Input Sensitivity-
1.2Vrms ( Line Volume = 0dB)
2.4Vrms ( XLR Volume = 0dB)
5mV (Phone MM, Gain = 46dB, Volume = 0dB)
1mV (Phone MC, Gain = 60dB, Volume = 0dB)
Input Impedance-
50K (Line)
50K // 100pF (Phono MM)
360R // 200pF (Phono MC)
Total Harmonic Distortion (THD)- < 0.0004% (1KHz @ 2V, Volume = 0dB)
Frequency Response- 20Hz - 20kHz (+/- 0.1dB)
Output Impedance- 120 ohm
Signal-to-Noise ratio-
>110dB (Line &XLR, A-weighted)
>78dB (Phono MM, A-weighted)
>70dB (Phono MC, A-weighted)
DAC
D to A Converter- ES9038Pro
Total Harmonic Distortion (THD)- <0.001% (1kHz@0dBFS)
Output Level (0dBFS, 1KHz)- 2.0Vrms
Max. Sampling Frequency-
Optical / Coaxial:192KHz
PC USB: PCM 768kHz, DSD512
Signal-to-noise Ratio (S/N)- >116dB (A-weighted)
Power Amplifier Section
Gain- +30dB
Rated Power Output- 2 x 200W (8 ohm, THD<1%)
Rated Power Output- 2 x 310W (4 ohm, THD<1%)
Frequency Response- 20Hz - 20kHz (+/-0.3dB)
Total Harmonic Distortion (THD)- <0.0008% (1kHz@100W/8ohm)
Input Sensitivity- 1.2Vrms
Signal-to-Noise Ratio (S/N)- >112dB (A-weighted)
Max. Output Current- 20A
Headphone Amplifier
Total Harmonic Distortion (THD)- < 0.01% (1kHz, 50mW )
Output Impedance- 2.35 ohm
Load Impedance- 20 - 600 ohm
General
Standby Power Consumption- <0.5W
Net Weight- 17.1kg
Gross Weight- 19.3kg
Dimensions (mm) (W x H x D)- 445 x 134.5 x 348mm
Carton Size (mm) (W x H x D)- 500 x 225 x 450mm
Finish- Black / Silver
Power Requirements (depending on region)-
220-240V ~ 50/60Hz
100-120V ~ 50/60Hz
Standard Accessories- Power Cord, Remote Control, User Manual
