Audio Analogue AAcento
DESCRIPTION
AAcento is the new integrated amp from Audio Analogue and the first product of the new PureAA line. This line is made to recall the philosophy used for the most successful Audio Analogue products: a mix of simple design and reference sound performances to create products with the best value for money available on the market.
PRODUCT DETAILS
Technical Specifications
Channels- 2
Phono Input- MM/MC
RCA inputs- 3
XLR inputs- 1
Pre-out- 1
Mono Out- 2
Input impedance- 47 kΩ
Power on 8Ω load- 100W @ 1% THD + N
Power on 4Ω load- 200W @ 1% THD + N
Power on 2Ω load- 300W @ 1% THD + N
Headphones Output Power(pure class A) 16Ω- 500mW
Headphones Output Power(pure class A) 32Ω- 1W
Headphones Output Power(pure class A) 300Ω- 120mW
Sensitivity(8Ω output nominal power)- 600mVRMS
Frequency Response(Att. 0dB, -3dB band)- 100KHz
Output resistance(2Ω nominal power and 1kHz)- 0.4Ω
Input Noise(Band limits 0Hz-80kHz/A-weighted)- ≈10µV/≈5µV
SNR- ≈100 dB
MM SNR- 85 dB
MC SNR- 65 dB
Physical Details
Standby power consumption(230VAC)- < 1W
Dimensions(HxWxD)- 92x445x400 mm
Weight- 14 Kg
