Arcam SA35

€3,495.00

The ARCAM SA35 is the all-in-one streaming system for the discerning music lover. It includes hard-won technologies for preserving the most delicate sounds and reproducing music with all its subtleties, nuances and excitement intact. Expertly designed in Cambridge UK, it includes an all-new digital audio and streaming platform, new linear toroidal power supply design, new user interface and new app.

The ARCAM SA35 is the all-in-one streaming system for the discerning music lover. It includes hard-won technologies for preserving the most delicate sounds and reproducing music with all its subtleties, nuances and excitement intact. Expertly designed in Cambridge UK, it includes an all-new digital audio and streaming platform, new linear toroidal power supply design, new user interface and new app.

PRODUCT DETAILS

Continuous power output (0.5% THD), per channel-
2 channels driven, 20Hz . 20kHz, 8O: 120W
2 channels driven, 1kHz, 4O: 200W
Harmonic distortion, 80% power, 8O at 1kHz: 0.002%

Analogue Inputs-
Number of inputs: 3 (RCA pairs)
Phono Inputs: MM and MC
Frequency response: 20Hz.20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 106dB

Digital Inputs-
Supported Streaming media: FLAC, WAV (LPCM), AAC, ALAC, AIFF, DSD (up to 256), MP3, MP4, OGG, WMA
Supported Streaming Bit depth: 16, 24, 32
Supported Streaming sample rates (kHz): Up to 384 kHz
Gapless Playback: Yes
Digital Audio Inputs: 1x HDMI eARC, 2x Coaxial (RCA), 2x Optical (Toslink)
Supported Digital input Bit depth: 16, 24
Supported Digital input sample rates (kHz): Up to 192 kHz
Frequency response (filter 1): 20Hz.20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 110dB

Wireless Specifications
Bluetooth Profile 5.4; A2DP Sink/Source, AVRCP, BLE,
Snapdragon Sound, AAC, LE Audio, Auracast
Bluetooth Transmitter Frequency and Power: 2,400 MHz to
2,483.5 MHz: <20dBm
Wi-Fi Network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi Transmitter Frequency Range and Power:
2400-2483.5 MHz (USA 11 Channels, Europe and Others 13 Channels): <20dBm
5G Wi-Fi Transmitter Frequency Range and Power:
5150-5250 MHz <23dBm
5250-5350 MHz <20dBm
5470-5725 MHz <20dBm (Not used in China)
5725-5850 MHz <14dBm for EU, <33dBm for other regions.

General

Mains voltage- 100V or 110–120V or 220–240V, 50–60Hz

Power consumption (maximum)- 700W

Power consumption (standby)- <0.5W

Dimensions W x D (including speaker terminals) x H (including feet)- 432 x 344 x 99mm

Weight (net): 12 kg

Supplied accessories-
Mains lead(s)
Remote control with 2 x AAA batteries
Measurement Microphone
5m USB Cable
Quick Start Guide
Important Safety Instructions
